The next evolution in our MBUS (Magpul Back-Up Sight) line, the MBUS 3 incorporates the best features, strengths and value of our original MBUS and MBUS Pro Sights in a feature-packed back-up sight system.
Significantly reduced in size from the MBUS, it sits at just 0.47” high when folded, 1.38” at its widest point, and weighs a scant 25 grams with hardware. Its aesthetics are derived from the MBUS Pro, but the MBUS 3 Front Sight is constructed of our impact-resistant polymer, making it lightweight and extremely durable. Featuring the same spring-loaded technology as its predecessor, they can be deployed with an ambidextrous push-button.
The MBUS 3 Front Sight sits at standard AR-height when deployed and includes tool-less elevation adjustment of a dual width enhanced front post similar to the MBUS Pro.
FEATURES
- Full-featured spring-loaded flip up sight
- Tool-less elevation adjustment and dual width enhanced front sight post, similar to MBUS Pro
- 0.47” high when folded and 1.38” wide at widest point
- Standard AR-height when deployed
- Impact-resistant polymer construction, smaller size provides light weight and resists operational abuse
- Clamps to most mil-std-1913 picatinny rails
- Made in the USA.
SPECS
- Position: Front
- Height above rail, stowed: ~0.47 in.
- Platform: AR10, AR15, M4, M16, M110, SR25
- Weight, w/ hardware: 25 g
ELEVATION ADJUSTMENT
- ~1 MOA (1.131”/100 m) per click with a 14.5" sight radius
- ~0.7 MOA (0.820”/100 m) per click with a 20" sight radius
*NOTE: Cannot be mounted to a railed gas block due to excess heat issues. Front MBUS must be mounted to a railed forend on the same plane as the receiver rail. Because of this the sight is also not compatible with MOE Hand Guards.
See all of our AR15s and AR15 parts here.
Make Model Fit:
AR-15.Universal
Color:
O.D. Green
Kit:
Model Number:
Material:
Polymer
Quantity:
1
Rifle Front Sight Type:
Flip-Up
Sight Color:
Gun Part Restrictions:
Yes
Ship to all EXCEPT:
Australia
Shop All ED BROWN
MBUS 3 Front Sight Flip-Up Adjustable Polymer ODG
Your Price
MAP:
$37.95
Crow # 100075129
MFR # MAG1166-ODG
UPC 840815132189
